Product Details:
Payment & Shipping Terms:
|
| Max. Speed: | 61 - 80km/h | Brake(F/R): | FRONT DISK / REAR DRUM |
|---|
|
Item |
Parameter |
Item |
Parameter |
|
|
L×W×H (mm) |
1890×655×1120 |
Front Tire |
120/70-12 |
|
|
Wheel Base (mm) |
1360 |
Rear Tire |
120/70-12 |
|
|
Ground Clearance (mm) |
150 |
Pressure Of Front Tire (kPa) |
200 |
|
|
Dry Weight kg |
115 |
Pressure Of Rear Tire (kpa) |
250 |
|
|
Max Payload kg |
150 |
Derailleur |
Auto Stepless
|
|
|
Turning Angle of Steering Handle º |
≤48 |
Speed Ratio of Derailleur |
6.89~22.39
|
|
|
V=60km/h |
Fr Brake Distance m |
Speed-down average m/s2 |
Rr Brake Distance m |
Speed-down average m/s2 |
|
|
≤37.3 |
≥4.4(5.8) |
≤54 |
≥2.9(5.8) |
|
Max speed (km/h) |
≥80 |
Engine type |
152QMI Single cylinder,4-Strake,Aircooled |
|
|
Economic Oil Consumption L/100km |
≤2.8 |
Bore/stroke(mm) |
52.4×57.8 |
|
|
Climbing Performance |
≥16 |
Displacement ml |
124.6 |
|
|
Start Model |
-1.3% |
Clutch |
Automatically centrifugal |
|
|
Starting type |
Electric start-up/down to start |
Oil capacity L |
6 |
|
Table5 continue
|
Item |
Parameter |
Item |
Parameter |
|
Lubricating Way |
Press and splash |
Ignition method |
CDI |
|
Rated Power kW/r/min |
5.2/7000 |
Fuse |
15A |
|
Max Torque N.m/r/min |
7.6/6000 |
Headlight |
12V35W/35W |
|
Compression Ratio
|
9.2:1 |
Tail Light/Brake light/license plate light |
LED |
|
Specification of Spark Plug |
C7HSA(NGK) or A7T,A7RT
|
License Plate Light |
12V 5W |
|
Spark Plug Gap mm |
0.6～0.7Eivissa |
Turning light |
LED |
|
Idling Speed r/min r/min |
(1700±170) |
Fuel Brand |
Above RQ90 |
|
Lubrication Capacity L |
0.9 |
Oil Capacity, Gearbox L |
0.11 |
|
Lubrication Brand |
SAE 80W/90 |
Gear Oil Brand |
SAE 80W/90 |
|
Battery |
12V 7Ah |
Valve Play |
0.03-0.05 |
