Product Details:
Payment & Shipping Terms:
|
Description:
1.Low speed with high torque adapts 2.Optimizing the heat engine system and transmission system improve the reliability of the engine.
3.Applying mass flow oil pump guarantees the reliability of the lubricating system. 4.Applying of the sphenoid starting clutch shortens the uniting time, improve the stability and
lower the noise.
5.The engine is equipped with electronic reverse protecting device to improve the operating safety
of the vehicle and make the vehicle easier to operate. 6Applying the new designed clutch guarantees of the transferring of the torque and lengthen the
life of the engine.
Specification:
|
Type |
Single cylinder4-strokesforced air-cooled |
|||
|
Model |
JL1P39QMB |
JL1P44QMC |
JL1P47QMD |
JL1P50QMG |
|
Cylinder(mm) |
39 |
44 |
47 |
50 |
|
Piston displacement(mm) |
41.5 |
41.5 |
41.5 |
41.5 |
|
Displacement(ml) |
49.6 |
63.1 |
72 |
81.5 |
|
Nominal power(kw/rpm) |
2.0/7500 |
2.3/7500 |
2.6/7500 |
3.2/7500 |
|
Max power(kw/rpm) |
2.2/8000 |
2.5/8000 |
2.8/8000 |
3.5/8000 |
|
Max Torque(N.m/rpm) |
2.6/6500 |
3.5/6500 |
3.8/6500 |
4.8/6500 |
|
Idle(r/min) |
2000±150 |
2000±150 |
2000±150 |
2000±150 |
|
Crankcase has general crankcase and lengthening by 30mm and lengthening by 60mm crankcase.Magneto have octuple-poles AC,octuple-poles DC,octuple-poles complete DC.above the engines can pass EuⅡ discharge standard.Non-secondary gas-filling engine can be produced upon request. |
||||
