| Fuel: | Electric | Transmission System: | Chain Drive |
|---|
Specification:
Engine Type: single-cylinder,water-cooled,4 stroke
Ignition: CDI
Compression Proportion: 10.0:1
Start mode: Electric start
Fuel tank capacity: 4L
Transmission mode: chain
Power:11.5kw/6500r/min
Max Torque:17.5N.m/5500r/min
Ground clear lance: 120mm
Max Speed: ≥75km/h
Battery 12V9Ah
Transmission: 4 gear one reverse manual clutch
Bore × Stroke (mm):63.5×62.2mm
Engine oil: 1L
Lubrication: press splash
Displacement: 229.2ml
Packing trig: mechanical lock
Front wheels: 21×7-10 Rear wheels: 20×10-10
Brake style (F/R): drum/disc
Front suspension: integral ballonet absorber
Rear suspension: inner ballonet absorber
Product dimensions: 1800×1120×1130mm
Carton dimensions: 1470×850×880mm
Wheelbase: 1150mm
Height of seats: 880mm
DRY Weight: 155kg
Load capacity: 150kg
Climbing degree: ≤20°
Mini Turning radius: 2650mm
Conveyance: Qty/20’FCL: 20 units; Qty/40’FCL: 44units; Qty/40’HQ: 66pcs
