Description:
Engine model L: C163FML
Engine type : Vertical,Single,double bank,4-stroke,wind-cooled
Cylinder displacement(ml): 193.3
Bore*Stroke :63.0×62.0
Maximum PowerKw/(r/min): 11.0 /7500
Maximum TorqueN·m/(r/min): 14.0/6000
Minimum fuel consumption(g/kW·h) : ≤354
Compression ratio : 9.0:1
Start type : Electrical
Transmission type : Chain
Brake type(F/R): Disc/Disc
Brake distance(m/20km): ≤7.00
Gear-Shifting type : 5-range constant mesh gear
Clutch type: manual,wet-type,multidisc clutch
L×W×H(mm): 2100×790×1160
Minimum turning radius (mm): 1900
Maximum gradability(°): ≥30°
Seat cushion (mm): 820
Min.Ground Clearance(mm): 200
Max.speed(kw/h) : ≥100
Tyre(F/R): 110/70-17/140/70-17(TubeLess)
Body kits materials: ABS
Colour: Red,Black,Blue
Packing size(mm) :1970×590×1400
N.W.(kg) :150
G.W.(kg) :170
Fuel tank Maximum capacity(L): 16
Primary transmission ratio :4.055
Final transmission ratio: 2.833
First gear: 2.769
Second gear: 1.882
Third gear: 1.4
Fourth gear: 1.13
Fifth gear: 0.96
Warranty Period: 6000KM /12 Months
