Product Details:
Payment & Shipping Terms:
|
Specifications:
|
Engine model |
LC163FML |
|
Engine type |
Vertical,Single,double bank,4-stroke,wind-cooled |
|
Cylinder displacement(ml) |
193.3 |
|
Bore*Stroke |
63.0×62.0 |
|
Maximum PowerKw/(r/min) |
11.0 /7500 |
|
Maximum TorqueN·m/(r/min) |
14.0/6000 |
|
Minimum fuel consumption(g/kW·h) |
≤354 |
|
Compression ratio |
9.0:1 |
|
Start type |
Electrical |
|
Transmission type |
Chain |
|
Brake type(F/R) |
Disc/Disc |
|
Brake distance(m/20km) |
≤7.00 |
|
Gear-Shifting type |
5-range constant mesh gear |
|
Clutch type |
manual,wet-type,multidisc clutch |
|
L×W×H(mm) |
2100×790×1160 |
|
Minimum turning radius (mm) |
1900 |
|
Maximum gradability(°) |
≥30° |
|
Seat cushion (mm) |
820 |
|
Min.Ground Clearance(mm) |
200 |
|
Max.speed(kw/h) |
≥100 |
|
Tyre(F/R) |
110/70-17/140/70-17(TubeLess) |
|
Body kits materials |
ABS |
|
Colour |
Red,Black,Blue |
|
Packing size(mm) |
1970×590×1400 |
|
N.W.(kg) |
150 |
|
G.W.(kg) |
170 |
|
Fuel tank Maximum capacity(L) |
16 |
|
Primary transmission ratio |
4.055 |
|
Final transmission ratio |
2.833 |
|
First gear |
2.769 |
|
Second gear |
1.882 |
|
Third gear |
1.4 |
|
Fourth gear |
1.13 |
|
Fifth gear |
0.96 |
|
Warranty Period: |
6000KM /12 Months |
