| Engine model | ZS165FML CBB200 |
| Engine type | Vertical,Single,double bank,4-stroke,wind-cooled |
| Cylinder displacement(ml) | 198.8 |
| Bore*Stroke | 65.5×59 |
| Maximum PowerKw/(r/min) | 11.0 /7500 |
| Maximum TorqueN·m/(r/min) | 14.0/6000 |
| Minimum fuel consumption(g/kW·h) | ≤354 |
| Compression ratio | 9.25:1 |
| Start type | Electrical |
| Transmission type | Chain |
| Brake type(F/R) | Disc/Disc |
| Brake distance(m/20km) | ≤7.00 |
| Gear-Shifting type | 5-range constant mesh gear |
| Clutch type | manual,wet-type,multidisc clutch |
| L×W×H(mm) | 1960*720*1100 |
| Minimum turning radius (mm) | 1900 |
| Maximum gradability(°) | ≥30° |
| Seat cushion (mm) | 820 |
| Min.Ground Clearance(mm) | 200 |
| Max.speed(kw/h) | ≥100 |
| Tyre(F/R) | 110/70-17/140/70-17(TubeLess) |
| Body kits materials | ABS |
| Colour | Red,Black,Blue |
| Packing size(mm) | 1970×590×1400 |
| N.W.(kg) | 150 |
| G.W.(kg) | 170 |
| Fuel tank Maximum capacity(L) | 16 |
| Primary transmission ratio | 4.055 |
| Final transmission ratio | 2.833 |
| First gear | 2.769 |
| Second gear | 1.882 |
| Third gear | 1.4 |
| Fourth gear | 1.13 |
| Fifth gear | 0.96 |
