Product Details:
Payment & Shipping Terms:
|
| Brake(F/R): | Front Hand Brake,back Kick Brake |
|---|
Applications:
Motorcycle, powered by gasoline engine, operate the front wheel steering with two wheel or 3 wheels. Lightweight flexible, driving fast. Widely used for patrol, passenger and cargo transportation, etc., it is a kind of wide application, fast, economic and comfortable means of vehicles. It has bicycles’ flexibility and portability, cars’ mobility and recommend suite at the same time.
Specifications:
|
Dimension ((L×W×H)mm): |
1920x770x1080 |
|
Wheel base(mm): |
1230 |
|
Min. Ground clearance (mm): |
140 |
|
Rim type: |
spoke |
|
Dry weight(kg): |
95 |
|
Front Tyre size and air pressure: |
2.25-17/175KPa |
|
Rear Tyre size and air pressure: |
2.50-17/200KPa |
|
Front. Brake: |
drum |
|
Rear. brake: |
drum |
|
Max.loading capacity(kg): |
150 |
|
Max. Speed (km/h): |
70 |
|
Economical fuel consumption (l/100km): |
1.8 |
|
Break Performance: |
≤7m/30km/h |
|
Max. Fork advancing angel (°): |
18 |
|
Max. Voice (dB(A): |
80 |
|
Engine technical data: |
|
|
Engine model: |
1P47FMD |
|
Engine type: |
single-cylinder, air-cooled,four-stroke |
|
Bore X Stroke (mm): |
47x41.4 |
|
Displacement (ml): |
72 OR 90 |
|
Compression ratio: |
7.0:1 |
|
Power (kw/r/min): |
3.6/7500 |
|
Max.torque (N.m/r/min): |
5.6/5000 |
|
Starting mode: |
Electric /Kick Start |
|
Ignition mode: |
CDI Electronic ignition |
|
Warranty Period: |
6000KM /12 Months |
