| Max. Speed: | > 80km/h | Brake(F/R): | FRONT DISK / REAR DRUM |
|---|
Specifications:
|
Overall size(LWH)(mm):2045*900*1095 Axile depth (mm):1340 Min.rode clearance (mm):130 Min.diameter of turning circle (mm):4000 Whole motorcycle weight(kg):124 Max.loading (kg):150 Max.weight:274 Start Performance (s):≤15 Max.speed (km/h):85 Max.climbing ability :≥16 |
||||||||||
|
Accelerating Performance |
start acceleration (s) |
≤16 |
||||||||
|
|
overruning acceleration (s) |
≤15 |
||||||||
|
Min.steady speed:km/h:22 |
||||||||||
|
Coast-down Distance (40km/h): ≥200m |
||||||||||
|
Tyre size and pressure |
FR |
3.00-18 ≤250 |
||||||||
|
|
RR |
3.50-16 ≤275 |
||||||||
|
Brake tyre and Operation |
FR |
disc/hand |
||||||||
|
|
RR |
drum/foot |
||||||||
|
Headlight Specification:W/V:35/12 |
||||||||||
|
Winker specification:W/V:10/12 |
||||||||||
|
Brake lamp W/V:21/12 |
||||||||||
|
Reliability (km):6000 |
||||||||||
|
Durability (km):16000 |
||||||||||
|
|
Cylinder diamter X Stroke |
56.5 X 49.5 |
||||||||
|
|
Cylinder volume |
124.5 |
||||||||
|
|
Compression ratio |
9:1 |
||||||||
|
|
Rated power and relevant speed |
6.8/8000 |
||||||||
|
|
Max.power and re levant speed |
7.2/8500 |
||||||||
|
|
Max.Distortion distance |
8.3/7500 |
||||||||
|
|
Min.no-load steady speed |
1500±150 |
||||||||
|
|
Min.Fuel consumption rate |
≤367 |
||||||||
|
|
Gasoline brands |
RQ90 |
||||||||
|
|
Start method |
electric start/kick start |
||||||||
|
|
Ignition method |
CDI |
||||||||
|
|
Clutch type |
Wet multi-disk |
||||||||
|
|
Transmission |
5-speed recycling |
||||||||
|
|
Transmission Speed ratio |
primary transmission ratio |
4.055 |
|||||||
|
|
|
Last transmission ratio |
2.8 |
|||||||
|
|
|
All levels transmission ratio |
first stage |
secend stage |
third stage |
forth stage |
fifth stage |
|||
|
|
|
|
2.769 |
1.882 |
1.400 |
1.130 |
0.960 |
|||
