Description:
Starter motor principle: the starter motor makes the battery electrical power into mechanical energy to drive the engine flywheel rotation to achieve engine starting.
Structure of the starter motor: DC motor, transmission, electromagnetic switches three parts.
Models:AG-50, GY6-80, TACT50, YBR125, GN250, CYRIPTON, CBX200, JOG50, VS125, ZY125, DIO50, YAMAHA100, TITAN200, V100, Kriss, Comel, GSX, Wave125, VR, LC135, EGO, Elit150, Tornado, Smash, Elegan, Click, Jaguh175, SRE, Shogun...
Applications:
Start motor is installed to engines(diesel/gasoline). Start the motor by the electrically driven , reducing the trouble of labor-starting, rapid start, reusable, widely used. Commonly used in, automotive engine start, generator start, start large-scale construction machinery and so on.
Specifications:
|
Battery
|
Voltage (V) |
12 |
Unloaded |
Voltage (V) |
11.5 |
|
Capacity (A) |
7 |
Current (A) |
≤15 |
||
|
Loaded
|
Torque (N.m) |
0.3 |
R.Speed (r/min) |
≥13000 |
|
|
Voltage (V) |
10 |
Halt
|
Voltage (V) |
6.5 |
|
|
Current (A) |
≤800 |
Current (A) |
≤150 |
||
|
R.Speed (r/min) |
≤6000 |
Torque (N.m) |
≥0.75 |
